Cathodic protection of titanium anode



Titanium anode & cathodic protection
MMO titanium anode tube, titanium anode, titanium rod, titanium wire anode, titanium conduction band, titanium mesh anode, titanium anode plate
Principle of cathodic protection
Corrosion of metals is a multi electrode coupled system. When the metal materials in contact with electrolyte solution, due to the electrochemical inhomogeneity on the surface of the metal, often form a corrosion cell. The galvanic corrosion cell can be simplified as a double electrode, therefore, cathodic protection can be realized through the following two methods.
1, the use of impressed current, make the entire surface of the protected metal structure of cathode, called the impressed current cathodic protection.
Impressed current cathodic protection, metal devices can use the metal wire is connected to one plus the power of the cathode, the another auxiliary anode is connected to the power of the anode. At this point, through the auxiliary anode current after flowing through the electrolyte solution, focused on cathode part of metal, is a metal cathode polarization occurs, the current through the cathode flow back to the power supply, so as to reduce the total potential of metal. If the protection current is large enough, the protected structure on the original anode dissolve, at this point is fully protected.
2, on the need to protect the metal equipment connected to a more negative potential of the metal or alloy, referred to as the sacrificial anode protection.
By the principle of cathodic protection, any metal structure for cathodic protection, should be specific the following conditions:
(1) the environment medium must be conductive. Because the media will constitute part of the cathodic protection system, this way can protection of current flow through the conductive medium, form a complete electrical circuit. In soil, water, acid and alkali medium such as salt solution can implement cathodic protection, but are not in the gas medium. Gas-liquid interface, dry-wet alternate parts protection effect is not good. In strong acid solution, due to protect current consumption is too big, also shoulds not be commonly use cathodic protection method.
(2) the metal material of the medium should be easy to cathodic polarization, or because of the consumption current is large and not suitable for the cathodic protection method. In a passive state of metal in the medium, cathodic protection should not be adopted.
(3) the protected metal structure geometry too complicated, otherwise the protection current distribution, a local phenomenon of inadequate protection or protection.
Current cathodic protection method is mainly used in the following media:
A: freshwater and seawater, prevent the ship, wharf, platform, gate and cooling equipment corrosion.
B: alkali and salty solutions, to prevent the reservoir, the erosion of the evaporation tank, alkali boil pot, etc.
C: in soil and mud, to prevent the corrosion of pipelines and cables, etc.
Cathodic protection is an effective way to control the corrosion, it can eliminate galvanic cell and galvanic corrosion and local corrosion and limitation. Has been widely used in underground cables, oil and gas pipelines, car parks, Bridges, coastal structure, drilling platforms, ships, and chemical industry, power generation equipment and many other anti-corrosion structure.
MMO get more and more application in the cathodic protection, it has the advantages of high current density, acid, long life, in fresh water, soil, water and concrete, etc. Metal of cathodic protection will be protected with cathode polarization, and to reduce the living for the purpose of preventing metal corrosion. General can adopt two kinds of schemes to implement:
1, the impressed current cathodic protection
Is impressed current cathodic protection by impressed current, that is to protect the entire surface of the metal structure as cathode. If metal equipment for impressed current cathodic protection, the metal with a plus the power wire is connected to the cathode, the another assistant anode anode from power supply. At this point, through the auxiliary anode current after flowing through the electrolyte solution, focused primarily on the metal cathode protection, cathodic polarization in the metal, the current through the cathode flow back to the power supply, so as to reduce the total potential of metal. If the protection current is large enough, the protected structure on the original anode dissolve, at this point, only the cathodic reduction reaction on the metal surface, and to achieve full protection. Cathode material selection for different use conditions of continuous development and improvement.
Metal oxide coated anode with titanium matrix, the surface with high catalytic activity of platinum group metal oxide coating, has the good electrical conductivity and the surface of the smaller output resistance, its itself is not affected by media, and the advantages of easy processing. To make it adapted to the different environment, such as sea water, fresh water, soil, etc.
2, the sacrificing anode protection
Sacrificial anode protection is on the protected metal connecting a more negative potential of metals as anode, with the protected metal in the electrolyte to form a larger battery. Pass pass ANiu by anodic electrolyte and into the metal equipment, and make the metal equipment of cathodic polarization and get the corresponding protection.
Application: underground metal structure of cathodic protection, pipeline, cathodic protection, seawater cathodic protection of steel structure
